Scheda grafica Colorful iGame GeForce RTX 3080 Vulcan OC 10G LHR-V, specifiche e parametri di riferimento

This section outlines the key features of the graphics card Colorful iGame GeForce RTX 3080 Vulcan OC 10G LHR-V.

• Basato su
  NVIDIA GeForce RTX 3080 LHR
• Chip GPU
  GA102-202-K1-A1
• Unità di esecuzione
  68
• Shader
  8704
• Unità di uscita del rendering
  96
• Unità di texture
  272

Specifications for onboard video memory, including type (e.g., GDDR6), capacity, and bandwidth. Higher capacity and bandwidth contribute to improved gaming and rendering performance.

• Dimensione della memoria
  10 GB
• Tipo di memoria
  GDDR6X
• Velocità della memoria
  1.188 GHz
• Banda di memoria
  760 GB/s
• Interfaccia di memoria
  320 bit

Information on the base and boost clock speeds of the graphics card, which directly affect its performance in gaming and rendering applications. Colorful iGame GeForce RTX 3080 Vulcan OC 10G LHR-V.

• Frequenza di base
  1.440 GHz
• Frequenza massima
  1.800 GHz+ 5 %
• Overclock
  Sì

Details on the thermal design power (TDP) of the graphics card, including the maximum thermal output under standard and overclocked conditions, guiding the selection of cooling solutions.

• TDP
  370 W+ 16 %
• TDP (up)
  --
• Tjunction max
  93 °C
• PCIe-Power
  3 x 8-Pin

Specifications of the cooling system, including fan types and configurations, which are critical for maintaining optimal operating temperatures during intensive workloads. Colorful iGame GeForce RTX 3080 Vulcan OC 10G LHR-V.

• Fan-Type
  Axial
• Cooler-Type
  Air cooling
• Ventilatore 1
  3 x 100 mm
• Noise (Idle)
  0 dB / Silent
• Ventilatore 2
  --
• Noise (Load)
  --

Detailed information about connectivity options, including HDMI, DisplayPort, and DVI interfaces, along with their respective capabilities and supported resolutions.

• Max. Visualizzazioni
  4
• Versione HDCP
  2.3
• Porte HDMI
  1x HDMI v2.1
• DP Ports
  3x DP v1.4a
• Porte DVI
  --
• VGA Ports
  --
• USB-C Ports
  --

An overview of the hardware capabilities of the graphics card, including support for technologies like ray tracing, DLSS, and Vulkan, which enhance graphical fidelity and performance.

• Risoluzione massima
  7680x4320
• DirectX
  12_2
• Raytracing
  Sì
• DLSS / FSR
  Sì
• LED
  iGame Energy Core

Support for various video codecs, such as H.264, HEVC, and VP9, which enhance video playback and streaming capabilities by offloading tasks from the CPU.

• h264
  Decode / Encode
• VP8
  Decode
• h265 / HEVC
  Decode / Encode
• VP9
  Decode
• AV1
  Decode

• Lunghezza
  323 mm
• Altezza
  159 mm
• Width
  61 mm
• Larghezza (slot)
  3 PCIe-Slots
• Weight
  --

• Interfaccia GPU
  PCIe 4.0 x 16
• Data di rilascio
  Q3/2021
• Release price
  --
• Processo tecnologico
  8 nm
• Part-no
  --
• Specifica
  data sheet

Posizioni comuni Colorful iGame GeForce RTX 3080 Vulcan OC 10G LHR-V GPU in benchmark popolari, per un confronto con altri modelli.

• FP32 Performance (Single-precision TFLOPS)
  201 place
• Battlefield 5
  237 place
• Shadow of the Tomb Raider
  251 place
• Crypto-Mining Ethereum Hashrate (MH/s)
  259 place
• Crypto-Mining Ergo Hashrate (MH/s)
  645 place
• Crypto-Mining Ravencoin Hashrate (MH/s)
  64 place
• 3DMark Benchmark
  255 place
• Crypto-Mining Vertcoin Hashrate (MH/s)
  742 place
